BitEdit Honda Keihin 1.5 NA

Product Description:

Software Activation From BitSoftware with Product Number: MK22915

Specs:

Manufacturer: BitSoftware

Module Honda Keihin 1.5 NA

Software module allows to edit calibrations of the Honda/Acura Petrol 1.5 normal aspirated vehicles with Keihin TC1782 ECUs.

Supported filesize: 2.5Mb.

Available maps:

Air Calculation: Air Charge Efficiency High VTEC& Air Charge Efficiency Low VTEC& Airmass flow through throttle body in additional mode& Exhaust back pressure after catalyst& Airmass flow through throttle body direct
Camshaft control: Target camshaft angle High VTEC& Target camshaft angle Low VTEC& Camshaft Angle at WOT High VTEC& Camshaft Angle at WOT Low VTEC
EGT: EGT Prediction MAP by Air Intake A/B
Fuel: MAP Fuel High VTEC in additional mode& MAP Fuel Low VTEC in additional mode
Idle: Desired idle speed& Desired idle speed after start A& Desired idle speed after start B
Injector control: Injector scaling in additional mode
Knock Limit: Spark advance limitation for knocking High VTEC& Spark advance limitation for knocking Low VTEC
Knock sensitivity: Knock Sensitivity
Limiters: Engine speed limitation
Load limitation: Load limitation High VTEC& Load limitation Low VTEC
Overrun Cutoff: Overrun Injector Restart RPM Cut& Overrun Injector Restart RPM Recover
Sensors scaling: Lambda sensor conversion& Mass air flow sensor scaling
Spark advance: Spark advance EGR dependent High VTEC& Spark advance EGR dependent Low VTEC& Spark advance retardation to reduce torque High VTEC& Spark advance retardation to reduce torque Low VTEC& Dwell time& Ignition Dwell Angle
Spark advance corrections: Spark advance correction by intake temperature
Spark Compensation: Water Temperature Ignition Advance& Water Temperature Ignition Retard
Target Lambda: Target Lambda at full load& Target lambda in closed loop& Target lambda limit for closed loop
Throttle valve control: Driving Force in additional mode& Throttle valve position linearization High VTEC& Throttle valve position linearization Low VTEC& Enable throttle valve opening
Torque: Torque Limit Torque Limitation (Test& if found)
VTEC: Engine speed to enable VTEC (Test& if found)

Vehicle speed limitation - NO support!
DTC mask - NO support!

Supported SW list for Module Honda Keihin 1.5 NA
