BitEdit GM ACDelco E92

Product Description:

Software Activation From BitSoftware with Product Number: MK22968

Specs:

Manufacturer: BitSoftware

Module GM ACDelco E92

Software module for editing calibrations ACDelco E92 ECUs of petrol normal aspirated GM vehicles (Chevrolet& Cadillac& etc.).

Available maps:

Fan Control: Desired FAN control& Desired FAN control via coolant temperature
Fuel: AFR target value as stoichiometry& Dynamic Airflow High RPM& Dynamic Airflow High RPM& Mass air flow sensor scaling
Fuel:Injector: Injector Flow Rate& Injector Flow Rate Density Multiplier& Injector Flow Rate Fuel Pressure multiplier
Fuel:Open Loop: Injection enrichment ratio open loop (alcohol)& Injection enrichment ratio open loop (gasoline)
Fuel:Power Enrich: Engine speed for enable power enrichment& Power enrichment& Pedal position for enable power enrichment& Power Enrich EQ Ratio vs. RPM& Torque threshold for enable power enrichment
Idle: Idle speed in motion& Startup idle speed in drive position& Startup idle speed in P/N& Target Idle Speed vs. Coolant Temp
Knock Control: Knock sensor threshold& Knocking fast attack rate& Maximal knock retardation& Maximal retardation step
Limiters: Vehicle speed limitation& Vehicle speed limitation minimum reverse& Vehicle speed limitation minimum
Requested torque: Requested torque normal mode& Requested torque reduced power mode
RPM Limits: Engine speed limitation& Engine speed limitation fuel cut off& Engine speed limitation extreme cut& Engine speed limitation extreme restore
Spark: Main spark advance high octane& Main spark advance low octane& Minimal final spark advance& Minimal spark advance& Minimal spark advance long& Optimal spark advance& Optimal spark advance (alcohol)& Spark advance cranking& Spark advance flex fuel
Torque Control: Maximal engine torque reverse gear& Maximal engine torque limitation& Peak engine torque& Torque limitation overboost
VVT: Exhaust camshaft correction by coolant temperature& Exhaust camshaft position by coolant temperature& Intake camshaft position full load& Exhaust camshaft position full load& Exhaust camshaft position high& Exhaust camshaft position high atmospheric pressure& Exhaust camshaft position low& Exhaust camshaft position medium& Intake camshaft position by coolant temperature& Intake camshaft position correction by coolant temperature& Intake camshaft position high& Intake camshaft position high atmospheric pressure& Intake camshaft position low& Intake camshaft position medium
DTC mask editor

Supported SW list for Module GM ACDelco E92
